Automatic Tube Filling Sealing Machine
Semi Automatic Tube Filling Sealing Machine
Tube Filling Sealing Machine with Hot Air Unit
The Tube Filling, Sealing & Coding System consists of main structure, tube moving with tube holding unit, safety acrylic enclosure (OPTIONAL), jacketed hopper with stirrer (OPTIONAL), filling nozzles, sealing head, coding unit, hot air sealing unit, electrical panel, PLC & HMI (OPTIONAL), mains on/off & motor.
The machine is manufactured or developed accordance with GMP standards. |
Structure is made of MS cladded with SS 304. |
This machine is specially designed to fill, seal and code the Aluminum / LAMI / PVC Tubes. |
It can be used to fill viscous as well as semi viscous materials in Aluminum / LAMI / PVC Tubes. |
Machine preset with 20gms to 100gms Piston & Cylinder. |
All the contact parts are made of SS 316 (GMP Model). |
Tube holders are made of nylon for different diameter of tube. |
Relay electrical control systems operating panel with START, STOP and INCH. |
SENSOR BASE NO TUBE NO FILLS MECHANISM. |
Specially designed hot air sealing unit to seal PVC tubes. |
Motor with variable speed. |
All moving parts are guarded / enclosed. |
Coding Device with 10 letters for one side. |
Hopper temperature thermocouple with digital display. |
Model | HMPL–TFS |
---|---|
Tube Diameter | 12 mm Ø to 50 mm Ø (Standard) |
Tube Length | 45 mm to 200 mm |
Filling Capacity | 10gms to 250gms Aluminum / LAMI / PVC Tubes (With the help of required change parts) |
Output Speed | 20 to 150 Tubes/Minute (Depending on viscosity of material, loading & fill capacity) |
Filling Accuracy | ± 1% of Filling Volume |
Power Supply | Three Phase / 440 V AC / 50 Hz |
Compressed Air | 4 to 5 Bar 100 L/Minute (If have sticky material) |
Hopper ** | 500 mm Ø 600 H |
Change Parts | a) Tube Holder b) Nozzle c) Auto Loader |
